HCDD 340

CSS Intro

Fixed seating arrangement for groups

HCDD 340

CSS Intro

Cascading Style Sheets (CSS)

  • Defines how different HTML elements look
    • styling texts
    • creating layouts (grids, multiple columns, …)
    • create animation

CSS rules for styling

styles.css from last class

section {
    position: absolute;
    top: 50%;
    left: 50%;
    margin-right: -50%;
    transform: translate(-50%, -50%);
}

.orange {
    color: #f0a202
}

Linking to CSS rules

index.html from last class

<head>
    ...
    <link rel="stylesheet" href="styles.css" />
    <title>Welcome to HCDD 340!</title>
</head>

CSS rules contain selectors and declarations

  • Select a specific items
  • Apply the style (declaration) to the selected items
    • property: value pairs

CSS rules contain selectors and declarations

Source

CSS rules contain selectors and declarations

section {
    position: absolute;
    top: 50%;
    left: 50%;
    margin-right: -50%;
    transform: translate(-50%, -50%);
}

CSS rules contain selectors and declarations

section {
    position: absolute;
    top: 50%;
    left: 50%;
    margin-right: -50%;
    transform: translate(-50%, -50%);
}

Selectors

Different “patterns” to identify match elements

Universal selector (*) matches all elements

* {
    margin: 0;
    padding: 0;
    box-sizing: border-box;
}

Type selector matches corresponding HTML elements

section {
    position: absolute;
    top: 50%;
    left: 50%;
    margin-right: -50%;
    transform: translate(-50%, -50%);
}

Matches all <section> elements

Type selector matches corresponding HTML elements

h4 {
    font-size: 1em;
}

Matches all <h4> elements

Class selector matches elements with a given class

.orange {
 color: #f0a202
}

styles.css

<h1 class="orange">HCDD 340</h1>
<h1>Goals</h1>

index.html

. is in CSS rules, but not in html

An element can have multiple classes

What happens in this case? 🤔

.orange {
 color: #f0a202
}

styles.css

<h1 class="orange another-class some-other-class">HCDD 340</h1>
<h1>Goals</h1>

index.html

Still matches (all elements containing the given class)

ID selector matches elements with the given id

#penn-state {
    border: 1px solid #96BEE6;
}

styles.css

<div id="penn-state">
We are!
</div>

index.html

# is in CSS rules, but not in html

Attribute selector matches elements with a given attribute or a value

Select element if a given attribute is present

[data-college] {
    color: #96BEE6;
}

styles.css

<div data-college="IST">Information Sciences and Technology</div>
<div data-college="HHD">Health and Human Development</div>

index.html

Both <div>s will match (i.e., attribute “college” is present)

Attribute selector matches elements with a given attribute or a value

Select element if the attribute has a given value

[data-college="IST"] {
    color: #96BEE6;
}

styles.css

<div data-college="IST">Information Sciences and Technology</div>
<div data-college="HHD">Health and Human Development</div>

index.html

What happens here?

Only the first <div> will be selected

You can do complex attribute matching

  • prefix and suffix matching (regular expression)
  • case insensitive
  • See more details here

Pseudo-classes

Pseudo-classes

Select a specific state of a given element (:)

h2:hover {
  color: blue;
}

Change outline when <h2> is hovered

Pseudo-classes

Select a specific state of a given element (:)

p:nth-child(even) {
  background: blue;
}

All even paragraphs will have blue background

Many pseudo-classes available

  • :first-child
  • :last-child
  • :visited

Source

Pseudo-elements

Pseudo-elements

Specific part of a selected element (::)

p::first-letter {
  color: goldenrod;
  font-weight: bold;
}

Changes the first letter of each paragraph — check it out

Pseudo-elements

::before and ::after for inserting elements

.exciting-text::after {
  content: " <- EXCITING!";
  color: darkgreen;
  font-weight: bolder;
}

.boring-text::after {
  content: " <- BORING";
  color: darkviolet;
  font-weight: bolder;
}

Check out the example

Grouping selectors

Apply same rule to multiple selectors

h1, h2, h3, h4, h5 {
    margin: 0 0 20px 0;
    line-height: 1.2;
    font-weight: bold;
}

Separated by commas

Combinators

Combine selectors to select elements in relation to others

  • Descendant
  • Child
  • Next-sibling
  • Subsequent-sibling

Descendant combinator

Parent and descendant selectors separated by a space

p strong {
  color: red;
}

All <strong> elements within <p> elements will have red color

What happens here?

li {
  list-style-type: disc;
}

li li {
  list-style-type: circle;
}

css

<ul>
  <li>Item 1
    <ul>
      <li>Subitem A</li>
      <li>Subitem B</li>
    </ul>
  </li>

html

Source

Child combinator

Parent and children selectors separated by a >

div > p {
    color: red;
}

Only the direct children will be selected (more restrictive than descendant combinator)

What happens here?

span {
  background-color: aqua;
}

div > span {
  background-color: yellow;
}

styles.css

<div>
  <span>
    Span #1, in the div.
    <span>Span #2, in the span that's in the div.</span>
  </span>
</div>
<span>Span #3, not in the div at all.</span>

index.html

Check it out!

Next sibling combinator

An element immediately follows another element within same parent (+)

img + p {
  font-weight: bold;
}

A paragraph that immediately follows an image (within same parent) will have bold text

Subsequent sibling combinator

An element immediately follows another element within same parent (~)

img ~ p {
}

Any paragraph that immediately follows an image (within same parent) will have bold text

Which ones are red: S1, S3, S4?

p ~ span {
  color: red;
}

styles.css

<article>
    <span>S1</span>
    <p>P1</p>
    <code>C1</code>
    <span>S2</span>
    <p>P3</p>
    <h1>H1</h1>
    <span>S3</span>
</article>
<span>S4</span>

index.html

Check it out!

Class activity

We will play CSS Diner

  • Work as a group
  • Feel free to use AI
  • How many levels can you complete?

How do the CSS rules work?

What happens if there are no CSS rules for a given page? 🤔

A browser will apply default styles

What happens when multiple rules apply?

Handling conflicts

h1 {
  color: red;
}
h1 {
  color: blue;
}

Handling conflicts

Cascading determines which rules actually apply

  • Position and order
  • Specificity
  • Origin
  • Importance

Source

Handling conflicts

Cascading determines which rules actually apply

  • Position and order
    • Immediate rule gets precedence
  • Specificity
  • Origin
  • Importance

Position and order

Immediate rule gets precedence

h1 {
  color: red;
}
h1 {
  color: blue;
}

The color will be blue

Immediate rule gets precedence

What’s the color of the button’s background?

button {
  background: yellow;
}

styles.css

...
<link rel="stylesheet"
    href="/styles.css" />
...
...
<button> I am a button </button>
<style>
    button { background: pink; }
</style>
</body>

index.html

pink — embedded style is more immediate

Source

Handling conflicts

Cascading determines which rules actually apply

  • Position and order
  • Specificity
  • Origin
  • Importance

Handling conflicts

Cascading determines which rules actually apply

  • Position and order
  • Specificity
    • More specific selectors gets precedence
  • Origin
  • Importance

More specific selectors gets precedence

A > B > C

Source

More specific selectors gets precedence

What’s the button color?

.branding {
  color: blue;
}

button {
  color: red;
}
<button class="branding">
    Hello, Specificity!
</button>

Blue — check it out!

More specific selectors gets precedence

A > B > C

Source

Handling conflicts

Cascading determines which rules actually apply

  • Position and order
  • Specificity
  • Origin
    • More specific origin takes precedence
  • Importance

Origin

More specific origin takes precedence

Source

Handling conflicts

Cascading determines which rules actually apply

  • Position and order
  • Specificity
  • Origin
  • Importance
    • You can use !important to change importance

Why my CSS rule is not applying? 🤯

Why my CSS rule is not applying? 🤯

Use Developer Tools

  • Firefox DevTools
    • Computed
  • Chrome DevTools
    • Styles

Source

Class activity

Starter files here

  • Unzip the file
  • Open the folder in VS Code
    • File –> Open Folder
  • Click on Show Preview
    • Top right corner
  • Also, open index.html in Chrome/Firefox

Todos

  • Only change styles.css
  • Paragraph directly after an <h2>:
    • bold
    • the first line: red
  • Even rows in a table
    • background color: #333333

Class activity

Hints

  • Paragraph directly after an <h2>:
    • Which combinator to use?
    • bold
    • the first line: red
  • Even rows in a table
